RFI
SKU:CSW24
RFI CSW24 UHF 4.5dB Phasemaster Whip (450-470 MHz); Black
RFI CSW24 UHF 4.5dB Phasemaster Whip (450-470 MHz); Black
Regular price
$38.60 AUD
Regular price
Sale price
$38.60 AUD
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Out of stock
View full details
RFI CSW24 UHF 4.5dB Phasemaster Whip (450-470 MHz); Black
Temporarily out of stock
The CSW20 Series Phasemaster™ antennas are our most popular roof mounts due to their unmatched performance and superior strength. The highly flexible stainless steel whip and consistent 4.5dB gain has made them a favourite in virtually all roof mount applications.
CSW24 Features:
• Outstanding performance - precisely matched phasing coil separating e wave over ½ wave electrical elements
• Supplied in colour coded bands then fine tuned in field with chart
• Black flexible 17-7PH Stainless steel whip will always bounce back after knocks and bumps.
Specifications:
| Brand | RFI |
| Frequency MHz | 450 - 470 |
| Tuned Bandwidth | 20 MHz @ <1.5:1 VSWR (<1.2:1 VSWR @ resonant frequency) |
| VSWR | 20 MHz @ <1.5:1 VSWR (<1.2:1 VSWR @ resonant frequency) |
| Nominal Gain [dBi] | 4.5 |
| Power [W] | 100 |
| Frequency Range [MHz] | 450 - 470 |
| Band | 450 - 470MHz |
| Tuning | Trim to frequency using supplied tuning chart |
| Cable And Connector | Not included, order separately |
| Whip Length mm | 608 |
| Whip Material | 17-7 PH Stainless steel with black high gloss plating |
| Packaging | Clear hanging bag |
| Antenna Type | Omni |
| Antenna Application | Vehicle Antenna |
| Frequency Band | UHF 380-520 MHz |
| Antenna Configuration | SISO |
Documentation
CSW24 Technical Specifications
Availability
3-4 Days Lead Time
